GOST 11358-89 PDF
Name in English:
GOST 11358-89
Name in Russian:
ГОСТ 11358-89
Dial-type thickness gauges and dial type wall thickness gauges graduated in 0,01 and 0,1 mm. Specifications
Full title and description
GOST 11358-89 — "Толщиномеры и стенкомеры индикаторные с ценой деления 0,01 и 0,1 мм. Технические условия" / English: "Dial-type thickness gauges and dial-type wall thickness gauges graduated in 0,01 and 0,1 mm. Specifications". The standard establishes technical requirements, types, basic dimensions and metrological limits for dial (indicator) thickness gauges and wall‑thickness gauges with scale divisions of 0.01 mm and 0.1 mm (measurement range up to 50 mm).
Abstract
GOST 11358-89 specifies constructional types (tabletop and handheld thickness gauges, and wall‑thickness gauges of types TН, TР, С etc.), accuracy classes, limits of permissible errors, requirements for measuring surfaces and measuring force, marking and examples of designations. It is intended to ensure interchangeability, repeatability and metrological reliability of indicator thickness and wall‑thickness gauges used in industrial measurement.
General information
- Status: Active / действующий.
- Publication date: Introduced 01 January 1990 (designation year 1989; ГОСТ 11358‑89).
- Publisher: ИПК «Издательство стандартов» / Государственный стандарт (USSR/Russia).
- ICS / categories: Metrology and measuring instruments — ICS 17.040 (relevant subgroups: 17.040.30 measuring instruments; 17.040.01 linear and angular measurements).
- Edition / version: Original designation ГОСТ 11358-89; contains at least one amendment recorded (Amd. 1, 1991 in original publishing notes).
- Number of pages: 8–9 pages (typical published PDF is 8–9 pages depending on source).
Scope
The standard applies to indicator‑type thickness gauges and wall‑thickness gauges with an upper measurement limit up to 50 mm and with indicator scale divisions of 0.01 mm and 0.1 mm. It establishes mandatory technical specifications for instrument types, main parameters and sizes, metrological performance (permissible errors and repeatability), measuring surfaces and measuring force, zero adjustment, marking and designation examples.
Key topics and requirements
- Types and constructional variants: tabletop (TН), handheld (TР) thickness gauges, and wall‑thickness gauges (С) with defined drawings and dimensional tables.
- Metrological characteristics: permissible error limits and repeatability (range and section up to 1 mm) under specified ambient conditions (20 ±5 °C, relative humidity, short‑term temperature change).
- Scale divisions: instruments with 0.01 mm and 0.1 mm divisions and associated accuracy classes.
- Requirements for measuring surfaces: flat measuring faces for thickness gauges and spherical measuring tips for wall‑thickness gauges with specified radii by type.
- Zero adjustment and regulation: limits for zero‑setting adjustment and arretir (locking) devices for certain types.
- Reference to indicator devices and related standards (example: dial indicator requirements per ГОСТ 577).
Typical use and users
Used by manufacturers, quality and metrology departments, repair shops and inspection laboratories for dimensional control of sheet and tubular parts, bushings, pipes and other hollow components where wall or material thickness must be measured. Typical users include instrument makers, mechanical workshops, calibration laboratories and procurement/specification engineers selecting hand or tabletop indicator gauges for production and inspection.
Related standards
References and relations include earlier or related GOSTs for measuring instruments and indicator devices (for example, predecessor GOST versions and documents cited in the standard), and specific standards for dial indicators and dimensional measuring equipment. The standard is also referenced by various product and material standards requiring thickness control. Example referenced document in the text: ГОСТ 577 (dial indicator requirements).
Keywords
thickness gauge; wall‑thickness gauge; dial gauge; indicator gauge; metrology; measurement accuracy; ГОСТ 11358‑89; thickness measurement; stenkomer; tolshchinomer.
FAQ
Q: What is this standard?
A: It is a national (GOST) technical specification that defines requirements for dial‑type thickness gauges and dial‑type wall‑thickness gauges with scale divisions 0.01 mm and 0.1 mm (GOST 11358‑89).
Q: What does it cover?
A: Types and dimensions, metrological performance (permissible errors and repeatability), measuring surface shapes, measuring force, zero adjustment, marking and examples of designation for instruments with measurement limits up to 50 mm.
Q: Who typically uses it?
A: Manufacturers of thickness and wall‑thickness gauges, quality control and metrology departments, calibration laboratories, mechanical workshops and engineers specifying inspection instruments.
Q: Is it current or superseded?
A: As recorded in document databases, ГОСТ 11358‑89 is listed as действующий (active). Users should verify any later amendments or national updates before application.
Q: Is it part of a series?
A: It sits within GOST documents covering dimensional measuring instruments and replaces earlier national editions for indicator thickness/wall gauges; it is used together with other dimensional metrology standards (e.g., standards for dial indicators and general measurement practice).
Q: What are the key keywords?
A: Thickness gauge, wall‑thickness gauge, indicator/dial gauge, metrology, measurement accuracy, 0.01 mm, 0.1 mm, ГОСТ 11358‑89.
