GOST 34385-2018 PDF

Full title and description

GOST 34385-2018 — "Буксы и адаптеры для колесных пар тележек грузовых вагонов. Общие технические условия" (English: "Axle-boxes and adapters for wheelsets of freight wagon bogies. General specifications"). The standard sets technical requirements, acceptance rules and test methods for axle-boxes (буксы), adapters and composite adapters used in freight-wagon bogies.

Abstract

This interstate standard establishes general specifications for axle-box housings and adapter components that sit between the outer rings of wheelset bearings and the support or thrust surfaces of wheelset openings in side frames of freight wagon bogies (primarily two-axle, three-piece bogies per GOST 9246). It defines material and mechanical requirements, dimensional and fitting rules, surface treatment and hardness, inspection and acceptance procedures, and test methods required for production and quality control. The standard may also be applied to components of three- and four-axle bogies where appropriate.

General information

• Status: Active / in force (introduced for the first time as an interstate standard; implemented as national standards in the participating states).
• Publication date: Approved May 24, 2018; issued 30 May 2018; effective (in Russia) from 1 December 2018 (dates of national implementation vary by country).
• Publisher: Interstate (Межгосударственный) standard adopted by the Interstate Council for Standardization, Metrology and Certification (EASC) and implemented in member states; introduced in Russia by the Federal Agency on Technical Regulating and Metrology (Rosstandart).
• ICS / categories: 45.060 — Railway engineering; rolling stock of railways.
• Edition / version: First edition — GOST 34385-2018 (with subsequent amendments/corrections published as noted in national indexes and amendment publications).
• Number of pages: 38 pages (typical published electronic/printed version).

Scope

The standard applies to axle-boxes and their constituent parts, adapters and composite adapters, and any other components of two-axle three-piece freight-wagon bogies (per GOST 9246) located between the outer rings of wheelset bearings and the support and/or thrust surfaces of the wheelset openings in side frames. It establishes general technical requirements, acceptance rules and control (inspection and test) methods. Application to axle-box parts and adapters of three- and four-axle bogies is permitted where appropriate.

Key topics and requirements

• Scope and definitions for axle-box housings, adapters and composite adapter parts used in freight-wagon bogies.
• Material and metallurgy requirements (per applicable GOST material standards for steels and castings), including referenced steel grades and casting specifications.
• Dimensional tolerances, fits and seatings for bearing bores, adapter interfaces and mating surfaces in accordance with rolling-stock fitting rules.
• Hardness and surface-treatment requirements for bearing support surfaces and thrust surfaces (including specified hardness values and measurement methods).
• Non-destructive and destructive test methods, mechanical testing (tensile, impact where required) and sampling regimes for acceptance.
• Inspection, marking, packing and documentation required for delivery and storage of axle-boxes and adapters.
• Normative references and cross-references to related rolling-stock standards (e.g., GOST 9246, bearing and wheelset specifications).

Typical use and users

Manufacturers of axle-box housings, adapters and related bogie components; rolling-stock equipment designers and engineers; railway vehicle repair and maintenance depots; quality and testing laboratories; procurement and certification bodies in railway industry supply chains. The standard is used as a technical specification for production, acceptance, inspection and maintenance operations.

Related standards

GOST 9246 (bogies two-axle three-piece for freight wagons), GOST 18572 (rolling bearings — axle-box roller bearings for rolling stock), GOST 4835 (wheelsets for freight and passenger cars), material standards (e.g., GOST 1050 for steels), and other GOST standards covering testing, tolerances and surface treatment referenced in the normative references section of GOST 34385-2018. These referenced documents provide the detailed material, bearing and measurement requirements that complement the general specifications of GOST 34385-2018.

Keywords

Axle-box; axle-box housing; adapter; composite adapter; wheelset; bogie; freight wagon; rolling stock; bearing seat; dimensional tolerances; acceptance tests; букса; адаптер; колесная пара; тележка; грузовой вагон.

FAQ

Q: What is this standard?

A: GOST 34385-2018 is an interstate (Межгосударственный) technical standard that defines general technical requirements, acceptance rules and test methods for axle-boxes and adapters used in freight-wagon bogies.

Q: What does it cover?

A: It covers axle-box housings, adapter parts and composite adapters located between bearing outer rings and support/thrust surfaces in bogie side frames. It specifies materials, dimensions and fits, hardness and surface-treatment requirements, inspection and acceptance tests, marking and packaging rules. Application to three- and four-axle bogies is allowed where appropriate.

Q: Who typically uses it?

A: Component manufacturers, rolling-stock designers, maintenance and repair depots, testing laboratories, quality and certification bodies and procurement specialists in the railway sector.

Q: Is it current or superseded?

A: As published, GOST 34385-2018 is active (in force). It was approved in May 2018 and introduced in member states with national implementation dates (e.g., effective 1 December 2018 in Russia). Amendments and corrigenda have been issued in national information indexes (check the national standards body updates for the implementing country to see the latest amendments).

Q: Is it part of a series?

A: It is not a sequential “series” standard number but belongs to the cluster of railway engineering standards under ICS 45.060 and is explicitly linked by normative references to other GOST standards governing bogies, bearings, wheelsets and materials (for example GOST 9246, GOST 18572 and related material/testing standards).

Q: What are the key keywords?

A: Axle-box, adapter, wheelset, bogie, freight wagon, bearing seat, dimensional tolerances, acceptance tests (Russian: букса, адаптер, колесная пара, тележка, грузовой вагон).
