SN RK 3.03-22-2013 PDF

Full title and description

SN RK 3.03-22-2013 (СН РК 3.03-22-2013) — "Промышленный транспорт" / "Industrial transport". This national construction norm of the Republic of Kazakhstan establishes design and functional requirements for industrial transport systems and associated infrastructure (railways of 1520 mm and 750 mm gauges, industrial roads, hydraulic pipelines, conveyor lines, cable/ropeway systems, loading/unloading facilities and related structures).

Abstract

SN RK 3.03-22-2013 defines general principles, technical parameters and safety requirements for the design, reconstruction and major repair of industrial transport facilities at industrial sites. It covers planning, earthworks, track and road superstructure, conveyors and pipelines, fire safety and environmental protection measures to ensure safe and efficient cargo movement within industrial enterprises.

General information

• Status: Active — approved by the Committee on Construction and put into force (entered into effect) on 1 July 2015.
• Publication date: Approved 29 December 2014 (order No. 156‑НҚ); published Astana 2015; in force from 1 July 2015.
• Publisher: Committee on Construction, Housing and Utilities and Land Management (under the Ministry of National Economy of the Republic of Kazakhstan). Developed by JSC KazNIISA and KarGTU.
• ICS / categories: Construction / civil engineering; Transport engineering; Industrial transport and infrastructure; Fire and environmental safety (applies to project standards for industrial transport facilities).
• Edition / version: SN RK 3.03-22-2013 (approved by order dated 29 Dec 2014; in force 01 Jul 2015).
• Number of pages: 28 (document length as available in commercial/standards catalogues).

Scope

This document applies to new construction, reconstruction, technical re-equipment and major repairs of industrial transport systems at production sites and industrial clusters. It sets normative requirements for multiple transport modes used within industrial enterprises: main and industrial railways (1520 mm and 750 mm gauges), internal roads, hydraulic (pipeline) transport and pumping stations, cable/ropeway systems, conveyor lines and loading/unloading facilities, together with requirements for earthworks, structures, fire safety and environmental protection.

Key topics and requirements

• Planning and longitudinal/profile requirements for tracks and roads (including track geometry and alignment).
• Design parameters for railways of 1520 mm and 750 mm gauges: earthworks, track superstructure and loading conditions.
• Roadway cross-section, pavement structure, drainage, intersections and protective works for internal industrial roads.
• Technical requirements for conveyor lines, conveyor route design and structural supports.
• Hydraulic transport: pipeline routing, pumping stations and associated hydraulic equipment requirements.
• Cable/ropeway (suspended) transport route, supports and load calculations.
• Fire safety provisions specific to each transport mode and site layout.
• Environmental protection measures related to construction and operation of industrial transport.

Typical use and users

Used by design institutes, engineering consultants, infrastructure planners, industrial facility owners/operators, construction contractors and regulatory authorities involved in the planning and design of industrial transport systems and related infrastructure at mines, plants, ports and large industrial complexes.

Related standards

Part of the SN RK / SP RK transport and construction normative framework (other related documents include СН РК series on railways, metro (metropolitan) design, airport/airfield standards and specific SP RK rules for industrial transport). SN RK 3.03-22-2013 is listed alongside other SN RK rules for transport in Kazakhstan’s construction normative base.

Keywords

industrial transport, SN RK 3.03-22-2013, industrial railway, conveyor, hydraulic transport, cable transport, internal roads, track design, fire safety, Kazakhstan construction norms

FAQ

Q: What is this standard?

A: SN RK 3.03-22-2013 is a set of Kazakhstani construction norms titled "Industrial transport" that establishes design and safety requirements for industrial transport systems and their infrastructure.

Q: What does it cover?

A: It covers design rules for multiple types of industrial transport (railways of 1520 mm and 750 mm, industrial roads, conveyors, hydraulic pipelines and pumping stations, cable/ropeway systems), plus requirements for earthworks, structures, fire safety and environmental protection relevant to industrial sites.

Q: Who typically uses it?

A: Design engineers, project offices, constructors, industrial operators, infrastructure planners and regulatory bodies responsible for industrial transport infrastructure use this standard in project design and review.

Q: Is it current or superseded?

A: As published, SN RK 3.03-22-2013 is listed as active and was put into effect on 1 July 2015. Users should verify whether any later amendments or replacement documents apply to their specific project before relying on the standard.

Q: Is it part of a series?

A: Yes — it is part of the SN RK transport and construction series of norms (SN RK 3.03.x and related SP RK documents) covering railways, metro, airports, industrial transport and other transport-related construction rules in Kazakhstan.

Q: What are the key keywords?

A: Industrial transport; railway 1520 mm; railway 750 mm; conveyors; hydraulic transport; cable transport; internal roads; fire safety; Kazakhstan construction norms.
